Why Rust is a great fit for embedded software
Rust is nice for a lot of things. At Tweede golf we've been using the language primarily for high-performance web applications. But that's not all Rust can do. Rust can be used to write embedded applications as well.

Update: this is the 2020 version. The 2023 update is here: Why Rust is a great fit for embedded software - 2023 update

I'd like to help you get an idea of whether Rust is a good fit for programming your next product with. Not only do I want to look at the general pros and cons, compared to the embedded lingua franca: C. I'm going to take you along writing a (very) basic embedded application in Rust as well. Rust for embedded? You be the judge!

Rust for embedded. Why? And why not?

Good questions, if I may say so myself. Compared to C, Rust is a relatively new language, which has its pros and cons. Like C, Rust can target low-level devices. However, Rust does a lot of things differently from C. Let's start with the things Rust has to offer.

Good stuff

Safety. That's one of the main selling points for Rust. It basically means that it's hard to accidentally introduce memory safety bugs when writing Rust. Rust makes unsafe operations explicit. It enforces the developer to think about what exactly they are doing. For example, reading uninitialized memory requires an explicit unsafe block. In Rust, using unsafe is like saying to the compiler: 'Even though you can't prove my code is correct, I'm sure I know what I am doing.' And then the developer can create a safe wrapper around that code, which enforces its user to interact with it in a correct manner. This way, the compiler can assure you that all non-unsafe parts are based on only well-thought-out code.

Speaking of compile-time guarantees, Rust has a strong type system. Rust's type system is comparable to C's in some ways: it defines structs, enums, and comparable primitive types. One thing Rust adds on top of that is traits. These traits are a means of defining what a type can do. For instance, in embedded systems, traits can describe which CPU pins can be configured as pulse-width modulation (PWM) outputs and how they should be configured. Used in this fashion, traits enable the compiler to dodge common headaches. They are essentially the data sheet, encoded in Rust. The compiler can help you avoid using a peripheral in an unsupported manner.

Type generics is another nice feature of Rust. They are a means to tell Rust that a function can take anything it likes, just as long as the type implements certain traits. For example, generics enable a developer to write a function to which any pin can be passed, as long as the pin can be configured as a PWM output. We can write a single function that can control any given PWM pin.

Last but not least, Rust is backed by a great community. Many Rustaceans are very willing to help out with solving bugs and other problems. Focusing on helping you improve, most community members stay positive even when asked the most trivial of questions.

Not everything is great

Rust is not all kittens and rainbows, though. Rust is not as mature as C. Debugging can be quite hard in embedded contexts, and most debug tooling is focused on C or C++ development. Although it's getting better fast, debugging Rust embedded applications can be a bit dodgy sometimes.

Rust being a relatively new language, there's not a lot of libraries or examples a developer can use to improve development speed. It means that sometimes, wheels need to be re-invented when developing embedded applications in Rust.

And let's not forget to address the elephant in the room. Rust is feared for its most prominent feature: the borrow checker. Simply stated, the borrow checker essentially enforces two rules. The first rule is that if there exists a reference with write access to a certain part of memory, this is the only reference to that part of memory. The second rule is that if shared references to a piece of memory exist, those references cannot be used to write to that piece of memory. Rust's borrow checker is a great tool for avoiding memory safety issues. It means, however, that you can't just go and structure your application as you would in C. Many people, myself included, experienced the steep learning curve that is introduced by 'fighting the borrow checker'.

Rust's safety features and generics, among other things, make the compiler do a lot of work it wouldn't have to do without them. Especially for larger projects, this can cause the compile times to go through the roof. Much effort is put into improving this, but as of this moment, it can really become an issue.

Nearly every platform can be programmed using C. In Rust, this is not so much the case. Being based on LLVM, Rust only targets platforms LLVM supports. One of the best-supported platforms is ARM Cortex-M. Xtensa (ESP32) or AVR CPU's are no first-class citizens in the LLVM ecosystem, even though they are quite commonly used.

Food for thought. I don't expect you to make any decisions on whether your next project should be in Rust, just based on a bunch of pros and cons. We need to go deeper!

Rust embedded applications in general

Embedded applications written in Rust usually have some things in common. Let's have a look at what those are. Being familiar with the options will help us when we're going to design the firmware.

Embedded systems don't have an operating system as your PC does. They don't have as many resources to spare for all the fancy functionality Linux or MacOS provide. Some embedded applications are built on top of a so-called Real-Time Operating System, or RTOS. Being lightweight, they offer certain guarantees about execution timing, as well as drivers for Bluetooth and networking. But Rust can be used on bare-metal systems as well. And when we do, there's no network stack or memory allocator available. We have to tell Rust that we don't want them, as they take up too many resources. This is done by putting the #![no_std] directive on top of the main source code file. With the directive in place, Rust won't include its standard library. We can only use Rust's core functionality.

Another thing Rust inserts by default is what's called a 'main-shim'. This shim loads the arguments the application was called with. There's no such thing in an embedded context. The CPU just boots and goes about doing what it is told. To disable insertion of the main-shim, we add the #![no_main] directive.

Loading 'er up

There are a couple of dependencies, or crates, many embedded applications in Rust use. On important one is embedded_hal. HAL is short for 'Hardware Abstraction Library'. And that's exactly what this crate is. embedded_hal provides traits that can be used to describe all kinds of peripherals and clocks. It enables you to write platform-agnostic drivers, which can run on any CPU Rust supports, and that has the right peripherals available. embedded_hal is the foundation for device-specific hardware abstraction libraries, as we'll see shortly.

Applications for ARM Cortex-M-based CPUs often depend on the cortex-m and cortex-m-rt crates. cortex_m provides low-level integrations with Cortex-M CPUs. Among other things, it gives us safe methods of interacting with configuration registers. The other crate, cortex_m_rt, helps us define the correct memory layout parameters. This is necessary in order to place the application at the correct spot in the CPUs memory. cortex_m_rt also helps us define the applications' entry point with the #[entry] directive it provides.

A very nice tool provided by the Rust Tools team is svd2rust. This tool can read System View Description (SVD) files, which contain information about a CPU's features. For instance, it describes where to put the bytes that need to be sent over UART. svd2rust converts these SVD files to a safe Rust API crate specific to a CPU. This type of crate is called a 'Peripheral access crate' or PAC. The PAC we are going to use is the stm32f3 crate, which provides abstractions to the peripherals of CPUs in the STM32F3xx family.

PACs generated with svd2rust contain a singleton Peripherals type, which contains proxies for all peripherals the CPU has. Internally, these proxies are just pointers to certain locations in memory, called registers. They are accompanied by functions with which we can write to or read from these registers, where appropriate. The Peripherals can only be obtained safely once. This means we'll either have to do the initialization in a central spot or, better yet, pass references to the appropriate registers to modules that need access to them. The need for passing references helps rule out conflicting configurations of registers. As the references are subject to the borrow checker's rules, no two pieces of code can alter the configuration of a peripheral while the other still has access to it.

Combining the output of svd2rust with the traits from embedded_hal, results in a device-specific HAL crate. These abstractions can be used to set up any platform-agnostic drivers based on embedded_hal. For the STM32F3xx family of CPUs, there's the stm32f3xx_hal HAL crate.

Why am I telling you all this? Because these tools are the bedrock of the application we're going to make. Let's have a look, shall we?

Let's get cookin'!

Before we begin: Setting up a development environment

Apart from obtaining the materials, we need to set up the development environment. This blog is not big enough to go into the details. If you want to try the code, please take a look at the Rust Discovery book. My advice is to read chapter 3 thoroughly. Apart from the tools described there, I'm using Visual Studio Code with the Rust Analyzer plugin, which provides me with code completion and other nice things.

Tutorials always start with a 'Hello World' example. This tutorial is no different. Except it ends there too. The embedded equivalent of 'Hello World' is a blinking LED. Fortunately, the Discovery board comes with a couple of LEDs soldered on. Easy as it may seem, blinking an LED can be done in very complicated manners. For this step, we just want to get some code running on the CPU. We'll take the quick'n'dirty way. When we're done, we'll have some basic pin set-up code, and an endless loop which switches one of the LEDs on and off, doing some busy waiting in between. This is what that looks like:

// The no_std and no_main directives you read about.
#![no_std]
#![no_main]

// Import a directive that marks the entry point of the application.
use cortex_m_rt::entry;

// Import the embedded_hal trait implementations for the STM32F303.
use stm32f3xx_hal::prelude::*;

// NOP means No-Op. It's an operation that does nothing.
// We use it in the busy waiting loops to notify Rust that it
// should not optimize these loops out, as we actually don't want
// to do anything for a while.
use cortex_m::asm::nop;

// A panic handler is run when the application encounters an error
// it cannot recover from. The handler defines what it should do
// in that case.
#[panic_handler]
unsafe fn panic_handler(_info: &core::panic::PanicInfo) -> ! {
    // On panic, just go do nothing for eternity,
    // or at least until device reset.
    loop {}
}

// This is the main function, or entrypoint of our applicaton.
#[entry]
fn main() -> ! {
    // Get a handle to the peripherals. Safe Rust allows only a single instance
    // of this handle. That way, accidental concurrent access is avoided.
    let peripherals = stm32f3xx_hal::stm32::Peripherals::take().unwrap();

    // Reset and clock control register. Among other things, this register
    // is for enabling the General Purpose Input/Output peripherals.
    // We constrain full access to the RCC, allowing access per part instead.
    // Individual modules can configure individual parts of the RCC
    // independently from now on.
    // This gets more important in larger applications.
    let mut rcc = peripherals.RCC.constrain();

    // The compass LEDs are all connected to the GPIO E peripheral.
    // Splitting the GPIO provides access to each of the individual pins,
    // so we can configure each of them independently.
    let mut gpioe = peripherals.GPIOE.split(&mut rcc.ahb);

    // The Northern LED is connected to pin pe9. To use it four our purpose,
    // we need to configure it to a push-pull output.
    // Import the parts of the type that describe pin pe9 when it's in
    // push-pull output mode.
    use stm32f3xx_hal::gpio::{gpioe, Output, PushPull};
    let mut led: gpioe::PE9<Output<PushPull>> = gpioe
        .pe9
        .into_push_pull_output(&mut gpioe.moder, &mut gpioe.otyper);

    // Loop forever
    loop {
        // Wait a couple of cycles
        for _ in 0..100_000 {
            nop();
        }
        // Enable the LED
        led.set_high().unwrap();
        // Wait some more
        for _ in 0..100_000 {
            nop();
        }
        // Disable the LED
        led.set_low().unwrap();
    }
}

Now, while Rust is pretty good at guessing which type my variables should be, I have explicitly noted the type of led: gpioe::PE9<Output<PushPull>>. While that might look very scary to you, it actually illustrates what is so nice about the Rust type system in embedded context. Every pin is of its own type: gpioe::PE9. And that type is generic over the pin mode: Output<PushPull>. This type provides the methods set_high and set_low. But the application won't compile if I try to read the pin's state. It should have been configured as an input for that. What's more, as a driver library writer, I can enforce my users to pass only correctly initialized peripheral references to my functions. Rust will statically check whether this is done correctly. How thoughtful of Rust to just let us know when we're doing something silly!

Conclusion

Using Rust for small examples like blinking an LED might seem overkill. But it does illustrate nicely how Rust's type system helps in correctly setting up device peripherals. In larger applications, this becomes a much bigger pro. Especially when multiple people are going to be writing it. And when you want to re-use the code.

The Rust compiler being the strict teacher that it is, helps avoid notorious memory safety bugs. As debugging and embedded device is a lot harder than inspecting, say, a browser application, this is an essential feature in our context. And ultimately, development speed will probably be higher than it would be with C.

Rust is young. It's becoming mature over time, but many things you can do with C cannot be done in Rust yet. But with devices like those from the STM32F3 family, which are pretty well supported by Rust, we think that Rust is a great language to write your embedded applications in.

We'd love to hear what you think over at r/rust.
